Wiring Colour Codes

A helpful guide as to what the wiring colour codes all mean. The mail ones being:

Brown direct from battery

Purple direct from battery via fuse

Green is via ignition

It also provides info as to which accessory or circuit it feeds.

colour_code_for_vehicle_wiring_-_new_order_2[35021].pdf
